GRUP TOBO
TOBO Perdagangan Internasional (Shanghia) Co., LtdTianda Oil Pipe Co., Ltd
Peralatan Pipa TOBO Co, Ltd Pipa TPCO & TISCO (Tianjin) Co, Ltd.
| Tempat asal: | Shanghai Cina |
|---|---|
| Nama merek: | TOBO |
| Sertifikasi: | ISO 9001 MTC TUV |
| Kuantitas min Order: | 1ton |
| Harga: | 600USD/Ton |
| Kemasan rincian: | Pengemasan Standar Layak Laut |
| Waktu pengiriman: | 8-15 hari |
| Syarat-syarat pembayaran: | D/P, T/T, Western Union, MoneyGram,Alipay |
| Menyediakan kemampuan: | 100000TON |
| merek: | TOBO | Standar: | API-5CT |
|---|---|---|---|
| Waktu pengiriman: | 8-15 hari | Tempat asal: | Shanghai Cina |
| Bentuk bagian: | Bulat | nama Produk: | Pipa |
| Paduan atau tidak: | Non-Paduan | Kemasan: | Pengemasan Standar Layak Laut |
| MOQ: | 1ton |
| Spesifikasi | API5CT/ISO 11960 |
| Bahan | L80, kelas baja |
| Diameter luar | 4 1/2″-20″, (114,3-508mm) |
| Ketebalan dinding | 1.0mm – 30mm |
| Dimensi Casing | 114,3 mm (4,5″) hingga 406,4 mm (16″) |
| Dimensi Tabung | 26,7 mm (1,05″) hingga 114,3 mm (4,5″) |
| Panjang | maks 12000mm |
| Jenis utas | SC (Benang bundar pendek), LC (Benang bundar panjang), BC (Benang Penopang) |
| API 5L | API 5L GR.42 / 46 / 52 / 56 / 60 / 65 / 70 / 80 |
| Nilai | C≤ | Si≤ | Mn≤ | P≤ | S≤ | Kr≤ | Ni≤ | Cu≤ | Juga≤ |
| API5CT L80 | 0,15-0,22 | 1.00 | 0,25-1,00 | 0,020 | 0,010 | 12.0-14.0 | 0,20 | 0,20 | 0,020 |
| Kualitas baja | Kekuatan Hasil (Mpa) | Kekuatan Tarik (Mpa) |
| API5CT L80 | 552-655 | ≥655 |
| Jenis tabung baja | Diameter luar | Ketebalan dinding | |
| Tabung canai dingin | Ukuran tabung (mm) | Toleransi (mm) | Toleransi (mm) |
| <114.3 | ±0,79 | -12,5% | |
| Ukuran | Berat | Diameter luar | Ketebalan dinding | Selesai Selesai | ||||||
| Nilai | ||||||||||
| di dalam | mm | di dalam | mm | J55K55 | L80 | N80 | C90T95 | P110 | ||
| 4 1/2 | 9.50 | 4.500 | 114.3 | 0,205 | 5.21 | PS | – | – | – | – |
| 10.50 | 0,224 | 5.69 | PSB | – | – | – | – | |||
| 11.60 | 0,250 | 6.35 | PSLB | PLB | PLB | PLB | PLB | |||
| 13.50 | 0,290 | 7.37 | – | PLB | PLB | PLB | PLB | |||
| 15.10 | 0,337 | 9.56 | – | – | – | – | PLB | |||
| 5 | 11.50 | 5.00 | 127.00 | 0,220 | 5.59 | PS | – | – | – | – |
| 13.00 | 0,253 | 6.43 | PSLB | – | – | – | – | |||
| 15.00 | 0,296 | 7.52 | PSLB | PLB | PLB | PLBE | PLB | |||
| 18.00 | 0,362 | 9.19 | – | PLB | PLB | PLBE | PLB | |||
| 21.40 | 0,437 | 11.10 | – | PLB | PLB | PLB | PLB | |||
| 23.20 | 0,478 | 12.14 | – | PLB | ||||||
| 24.10 | 0,500 | 12.70 | – | PLB | ||||||
| 5 1/2 | 14.00 | 5.500 | 139.7 | 0,244 | 6.20 | PS | – | – | – | – |
| 15.50 | 0,275 | 6.98 | PSLB | – | – | – | – | |||
| 17.00 | 0,304 | 7.72 | PSLB | PLB | PLB | PLBE | PLB | |||
| 20.00 | 0,361 | 9.17 | – | PLB | PLB | PLBE | PLB | |||
| 23.00 | 0,415 | 10.54 | – | PLB | PLB | PLBE | PLB | |||
| 6 5/8 | 20.00 | 6.625 | 168.28 | 0,288 | 7.32 | PSLB | – | – | – | – |
| 24.00 | 0,352 | 8.94 | PSLB | PLB | PLB | PLBE | PLB | |||
| 28.00 | 0,417 | 10.59 | – | PLB | PLB | PLBE | PLB | |||
| 32.00 | 0,475 | 12.06 | – | PLB | PLB | PLBE | PLB | |||
| 7 | 17.00 | 7.00 | 177.80 | 0,231 | 5.87 | – | – | – | – | – |
| 20.00 | 0,272 | 6.91 | PS | – | – | – | – | |||
| 23.00 | 0,317 | 8.05 | PSLB | PLB | PLB | PLBE | – | |||
| 26.00 | 0,362 | 9.19 | PSLB | PLB | PLB | PLBE | PLB | |||
| 29.00 | 0,408 | 10.36 | – | PLB | PLB | PLBE | PLB | |||
| 32.00 | 0,453 | 11.51 | – | PLB | PLB | PLBE | PLB | |||
| 35.00 | 0,498 | 12.65 | – | PLB | PLB | PLBE | PLB | |||
| 38.00 | 0,540 | 13.72 | – | PLB | PLB | PLBE | PLB | |||
| 7 5/8 | 24.00 | 7.625 | 193.68 | 0,300 | 7.62 | – | – | – | – | – |
| 26.40 | 0,328 | 8.33 | PSLB | PLB | PLB | PLBE | PLB | |||
| 29.70 | 0,375 | 9.52 | – | PLB | PLB | PLBE | PLB | |||
| 33.70 | 0,430 | 10.92 | – | PLB | PLB | PLBE | PLB | |||
| 39.00 | 0,500 | 12.70 | – | PLB | PLB | PLBE | PLB | |||
| 42.80 | 0,562 | 14.27 | – | PLB | PLB | PLB | PLB | |||
| 45.30 | 0,595 | 15.11 | – | PLB | PLB | PLB | PLB | |||
| 47.10 | 0,625 | 15.88 | – | PLB | PLB | PLB | PLB | |||
| 8 5/8 | 24.00 | 8.625 | 219.08 | 0,264 | 6.71 | PS | – | – | – | – |
| 28.00 | 0,304 | 7.72 | – | – | – | – | – | |||
| 32.00 | 0,352 | 8.94 | PSLB | – | – | – | – | |||
| 36.00 | 0,400 | 10.16 | PSLB | PLB | PLB | PLBE | PLB | |||
| 40.00 | 0,450 | 11.43 | – | PLB | PLB | PLBE | PLB | |||
| 44.00 | 0,500 | 12.70 | – | PLB | PLB | PLBE | PLB | |||
| 49.00 | 0,557 | 14.15 | – | PLB | PLB | PLBE | PLB | |||
| 9 5/8 | 32.30 | 9.625 | 244.48 | 0,312 | 7.92 | – | – | – | – | – |
| 36.00 | 0,352 | 8.94 | PSLB | – | – | – | – | |||
| 40.00 | 0,395 | 10.03 | PSLB | PLB | PLB | PLBE | – | |||
| 43.50 | 0,435 | 11.05 | – | PLB | PLB | PLBE | PLB | |||
| 47.00 | 0,472 | 11.99 | – | PLB | PLB | PLBE | PLB | |||
| 53.50 | 0,545 | 13.84 | – | PLB | PLB | PLBE | PLB | |||
| 58.40 | 0,595 | 15.11 | – | PLB | PLB | PLB | PLB | |||
| 10 3/4 | 32.75 | 10.75 | 273.05 | 0,279 | 7.09 | – | – | – | – | – |
| 40,50 | 0,350 | 8.89 | PSB | – | – | – | – | |||
| 15.50 | 0,400 | 10.16 | PSB | – | – | – | – | |||
| 51.00 | 0,450 | 11.43 | PSB | PSB | PSB | PSBE | PSB | |||
| 55.50 | 0,495 | 12.57 | – | PSB | PSB | PSBE | PSB | |||
| 60,70 | 0,545 | 13.84 | – | – | – | PSBE | PSB | |||
| 65.70 | 0,595 | 15.11 | – | – | – | PSB | PSB | |||
| 13 3/8 | 48.00 | 13.375 | 339.73 | 0,330 | 8.38 | – | – | – | – | – |
| 54.50 | 0,380 | 9.65 | PSB | – | – | – | – | |||
| 61.00 | 0,430 | 10.92 | PSB | – | – | – | – | |||
| 68.00 | 0,480 | 12.19 | PSB | PSB | PSB | PSB | PSB | |||
| 72.00 | 0,514 | 13.06 | – | PSB | PSB | PSB | PSB | |||
| 16 | 65.00 | 16 | 406.40 | 0,375 | 9.53 | – | – | – | – | – |
| 75.00 | 0,438 | 11.13 | PSB | – | – | – | – | |||
| 84.00 | 0,495 | 12.57 | PSB | – | – | – | – | |||
| 109.00 | 0,656 | 16.66 | P | P | P | – | P | |||
| 18 5/8 | 87.50 | 18.625 | 473.08 | 0,435 | 11.05 | PSB | – | – | – | – |
| 20 | 94.00 | 20 | 508.00 | 0,438 | 11.13 | PSLB | – | – | – | – |
| 106.50 | 0,500 | 12.70 | PSLB | – | – | – | – | |||
| 133.00 | 0,635 | 16.13 | PSLB | – | – | – | – | |||
