GRUP TOBO
TOBO Perdagangan Internasional (Shanghia) Co., LtdTianda Oil Pipe Co., Ltd
Peralatan Pipa TOBO Co, Ltd Pipa TPCO & TISCO (Tianjin) Co, Ltd.
| Tempat asal: | Cina |
|---|---|
| Nama merek: | TOBO |
| Sertifikasi: | SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED |
| Nomor model: | Ujung Rintisan |
| Kuantitas min Order: | 1 pc |
| Harga: | USD Depending on quantity |
| Kemasan rincian: | KASUS KAYU LAPIS ATAU PALLET |
| Waktu pengiriman: | 10-100 hari tergantung pada kuantitas |
| Syarat-syarat pembayaran: | L/C, T/T, Western Union |
| Menyediakan kemampuan: | 3.0000pcs per bulan |
| Bahan: | UNSS31803 | DN: | 15-1200 |
|---|---|---|---|
| Ukuran: | 1-48 inci | Jenis: | Mulus atau las |
| Standar: | DIN, EN, ASTM, BS, JIS, GB, dll. |
Welsure Hot Jual Stainless Steel Lap Joint Flange Fitting Pipa WP316/316L DN100 4 "SCH10S Stub End
Spesifikasi
1. Ujung rintisan baja tahan karat
2.sch5s-schxxs
3.ISO9001,ISO9000
4.Pasar: Amerika, Afrika, Timur Tengah, Asia Tenggara
| Tipe Siku | Ujung rintisan baja tahan karat. |
| Standar | ASME/ANSI B16.9 MSS SP-43 |
| Ukuran | 1/2''~48''(Mulus);16''~72''(Dilas) |
| ketebalan dinding | Sch5~Sch160XXS |
| Proses manufaktur | Dorong, Tekan, Tempa, Cast, dll. |
| Bahan | Baja karbon, baja tahan karat, baja paduan, baja tahan karat dupleks, baja paduan nikel |
| Baja karbon | ASTM A234 WPB, WPC; |
| Besi tahan karat |
304/SUS304/UNS S30400/1.4301 304L/UNS S30403/1.4306; 304H/UNS S30409/1.4948; 309S/UNS S30908/1.4833 309H/UNS S30909; 310S/UNS S31008/1.4845; 310H/UNS S31009; 316/UNS S31600/1.4401; 316Ti/UNS S31635/1.4571; 316H/UNS S31609/1.4436; 316L/UNS S31603/1.4404; 316LN/UNS S31653; 317/UNS S31700; 317L/UNS S31703/1.4438; 321/UNS S32100/1.4541; 321H/UNS S32109; 347/UNS S34700/1.4550; 347H/UNS S34709/1.4912; 348/UNS S34800; |
| Baja paduan |
ASTM A234 WP5/WP9/WP11/WP12/WP22/WP91; ASTM A860 WPHY42/WPHY52/WPHY60/WPHY65; ASTM A420 WPL3/WPL6/WPL9; |
| Baja dupleks |
ASTM A182 F51/S31803/1.4462; ASTM A182 F53/S2507/S32750/1.4401; ASTM A182 F55/S32760/1.4501/Zeron 100; 2205/F60/S32205; ASTM A182 F44/S31254/254SMO/1.4547; 17-4PH/S17400/1.4542/SUS630/AISI630; F904L/NO8904/1.4539; 725LN/310MoLN/S31050/1.4466 253MA/S30815/1.4835; |
| Baja paduan nikel |
Paduan 200/Nikel 200/NO2200/2.4066/ASTM B366 WPN; Paduan 201/Nikel 201/NO2201/2.4068/ASTM B366 WPNL; Paduan 400/Monel 400/NO4400/NS111/2.4360/ASTM B366 WPNC; Paduan K-500/Monel K-500/NO5500/2.475; Paduan 600/Inconel 600/NO6600/NS333/2.4816; Paduan 601/Inconel 601/NO6001/2.4851; Paduan 625/Inconel 625/NO6625/NS336/2.4856; Paduan 718/Inconel 718/NO7718/GH169/GH4169/2.4668; Paduan 800/Incoloy 800/NO8800/1.4876; Paduan 800H/Incoloy 800H/NO8810/1.4958; Paduan 800HT/Incoloy 800HT/NO8811/1.4959; Paduan 825/Incoloy 825/NO8825/2.4858/NS142; Paduan 925/Incoloy 925/NO9925; Hastelloy C/Paduan C/NO6003/2.4869/NS333; Paduan C-276/Hastelloy C-276/N10276/2.4819; Paduan C-4/Hastelloy C-4/NO6455/NS335/2.4610; Paduan C-22/Hastelloy C-22/NO6022/2.4602; Paduan C-2000/Hastelloy C-2000/NO6200/2.4675; Paduan B/Hastelloy B/NS321/N10001; Paduan B-2/Hastelloy B-2/N10665/NS322/2.4617; Paduan B-3/Hastelloy B-3/N10675/2.4600; Paduan X/Hastelloy X/NO6002/2.4665; Paduan G-30/Hastelloy G-30/NO6030/2.4603; Paduan X-750/Inconel X-750/NO7750/GH145/2.4669; Paduan 20/Tukang Kayu 20Cb3/NO8020/NS312/2.4660; Paduan 31/NO8031/1.4562; Paduan 901/NO9901/1.4898; Incoloy 25-6Mo/NO8926/1.4529/Incoloy 926/Paduan 926; Inconel 783/UNS R30783; NAS 254NM/NO8367; monel 30C Nimonic 80A/Paduan Nikel 80a/UNS N07080/NA20/2.4631/2.4952 Nimonik 263/NO7263 Nimonic 90/UNS NO7090; Incoloy 907/GH907; Nitronik 60/Paduan 218/UNS S21800 |
| Kemasan | Kotak kayu, palet, tas nilon atau sesuai kebutuhan pelanggan |
| MOQ | 1 buah |
| Waktu pengiriman | 10-100 hari tergantung kuantitas |
| Syarat pembayaran | T/T atau Western Union atau LC |
| Pengiriman | FOB Tianjin/Shanghai, CFR, CIF, dll |
| Aplikasi | Minyak Bumi/Tenaga/Kimia/Konstruksi/Gas/Metalurgi/Pembuatan Kapal dll |
| Perkataan | Bahan dan gambar lain tersedia. |
|
Selamat datang untuk menghubungi kami.
|
|
Nama Produk:Ujung rintisan Fitting Stainless Steel Pengelasan Butt
Kisaran Ukuran:
DN15-DN600 (1/2"-24") Tipe Mulus
DN15 - DN1200 (1/2"- 48") Tipe dilas
Ketebalan dinding:SCH5 hingga SCH160
Bahan:
Baja Karbon: ASTM A234 WPB, WPC, ASTM A420 WPL1, WPL3, WPL6 dll
Baja Tahan Karat: ASTM A403 WP304/304L, WP316/316/L, WP317L, WP321, WP347 & WPS31254
Baja Paduan: ASTM A234 WP1/WP12/WP11/WP22/WP5/WP7/WP9/WP91
Baja dupleks dan super dupleks: ASTM A815 UNS S31803/S32205/S32750/S32760
DIN 1.4301,1.4401,1.4404,1.4541,1.4401,1.4571 dll
Standar Pembuatan:
ASME B16.9,ASME B16.11,ASME B16.28 ,MSS SP-43,JISB2311,JIS B2312,JIS B2313,DIN 2605,DIN 2606 ,DIN2615,DIN2616 ,BG12459-90,GB/T13401,HGJ514 ,SH340 8 , SH3409, HG/T21635, HG/T21631,
Kemiringan Akhir:Sesuai dengan standar atau kebutuhan pelanggan
Pengobatan permukaan:Minyak hitam yang tahan karat dan meledak
Pengujian non destruktif:uji penetrasi, uji ultrasonik, uji radiografi, inspeksi pihak ketiga,
| Nama | Ujung rintisan pipa pendek/panjang baja tahan karat bertekanan tinggi, ujung rintisan sambungan putaran |
| Ukuran | 21.3mm-609.6mm (1/2''-24''),DN15-DN600 |
| WT | SCH5S-XXS |
| Standar | ANSI B16.9, ANSI B16.28, DIN 2605, ISO3419,DIN EN10253,JIS B2312, JIS B2313, MSS SP-25, MSS SP-75, BS1387,ASTM A403 |
| Bahan baku | Baja karbon, baja tahan karat, baja paduan |
| Baja karbon | 10#20#Q235B ASTM A234 ASTM A105 ASTM A403 |
| Besi tahan karat | 1Cr18Ni9Ti 0Cr18Ni9 00Cr19Ni10 0Cr17Ni12Mo2Ti 00Cr17Ni14Mo2 304 304L 316 316L |
| Baja Paduan |
16Mn Cr5Mo 12Cr1MoV 10CrMo910 15CrMo 12Cr2Mo1 A335P22 St45.8 ASTM A860 WPHY X42 X52 X60 X70 |
| Baja Aluminium | 1060,2024,2017,3003,5052,5083,6061,6083,6060,7075,8011 |
| Sedang mengemas: | Kotak kayu, palet kayu, atau sesuai kebutuhan pelanggan |
| Perlengkapan pipa utama |
Siku, Tee/Silang, Peredam, Tutup, Flensa, Tekuk, Stubtube, Weldolet/Threadolet/Olet, Nipple, Mengurangi Sisipan Soket, Penyatuan, Penjepit Pipa, dan lain-lain |
| Inspeksi | Inspeksi internal pabrik atau Pihak Ketiga |
| Aplikasi | Industri minyak bumi, Perusahaan Kilang, industri pupuk, pembangkit listrik, pembuatan kapal, anjungan darat |
