UNS 6601 UNS 6625 UNS 10276 Butt Weld Fittings Weldable Siku, Mengurangi Tee

Tempat asal	Cina
Nama merek	TOBO
Sertifikasi	SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED
Nomor model	UNS 6601 (INCONEL 601), UNS 6625 (INCONEL 625), UNS 10276 (HASTELLOY C 276)
Kuantitas min Order	3PCS
Harga	Dapat dinegosiasikan
Kemasan rincian	KASUS ply-WOODEN OR PALLET
Waktu pengiriman	15days
Syarat-syarat pembayaran	T/T, L/C, Western Union
Menyediakan kemampuan	9980000PCS Per Bulan

Detail produk

Bahan kelas	UNS 6601 (INCONEL 601), UNS 6625 (INCONEL 625), UNS 10276 (HASTELLOY C 276)	Standar	ASME B16.9, ASME B16.25, MSS SP-75 DIN2617 JISB2311 JISB2312 JISB2313
Proses manufaktur	Push, Press, Forge, Cast, dll	Aplikasi	Petroleum / Daya / Kimia / Konstruksi / Gas / Metalurgi / Kapal dll
Rincian Kemasan	pantat pengelasan pipa fitting umumnya harus dikirimkan dalam kasus kayu, palet kayu atau sesuai per	Uji	Spektrum cahaya bacaan langsung, uji hidrostatik, detektor sinar-X, deteksi cacat ultrasonik, detekt
Menyoroti	alat kelengkapan pipa dilas butt , alat kelengkapan pipa industri

Tinggalkan pesan

Deskripsi Produk

UNS 6601 UNS 6625 UNS 10276 Butt Weld Fittings Weldable Siku, Mengurangi Tee

Paduan nikel

ASTM / ASME SB 163 UNS 2200 (NICKEL 200)
ASTM / ASME SB 163 UNS 2201 (NICKEL 201),
ASTM / ASME SB 163/165 UNS 4400 (MONEL 400)
ASTM / ASME SB 464 UNS 8020 (ALLOY 20/20 CB 3),
ASTM / ASME SB 704/705 UNS 8825 INCONEL (825)
ASTM / ASME SB 167/517 UNS 6600 (INCONEL 600)
ASTM / ASME SB 167 UNS 6601 (INCONEL 601),
ASTM / ASME SB 704/705 UNS 6625 (INCONEL 625)
ASTM / ASME SB 619/622/626 UNS 10276 (HASTELLOY C 276)
Paduan tembaga
ASTM / ASME SB 111 UNS NO. C 10100, 10200, 10300, 10800, 12000,12200, 70600, 71500.
ASTM / ASME SB 466 UNS NO. C 70600 (CU -NI- 90/10), C 71500 (CU -NI- 70/30)
Baja Tahan Karat & Dupleks
Besi tahan karat
ASTM / ASME SA 312 GR. TP 304, 304L, 304H, 309S, 309H, 310S, 310H, 316, 316TI, 316H, 316 LN, 317, 317L, 321, 321H, 347, 347 H, 904L.
ASTM / ASME SA 358 CL 1 & CL 3 GR. 304, 304L, 304H, 309S, 309H, 310S, 310H, 316, 316H, 321, 321H, 347.
Baja Dupleks
ASTM / ASME SA 790 UNS NO S 31803, S 32205, S 32550, S 32750, S 32760.
Karbon & Baja Paduan
Baja karbon
ASTM / ASME A 53 GR. A & B, ASTM A 106 GR. A, B & C. API 5L GR. B, API 5L X 42, X 46, X 52, X 60, X 65 & X 70.
ASTM / ASME A 691 GRA, B & C
Baja paduan
ASTM / ASME A 335 GRP 1, P 5, P 9, P 11, P 12, P 22, P 23, P 91
ASTM / ASME A 691 GR 1 CR, 1 1/4 CR, 2 1/4 CR, 5 CR, 9CR, 91

Ukuran Pipa Norminal	Diameter Luar di Bevel				Center to End
DN	D1		D2		C	M.
DN	Seri A	Seri B	Seri A	Seri B	C	M.
20 × 20 × 15	26.9	25	21.3	18	29	29
25 × 25 × 20	33.7	32	26.9	25	38	38
25 × 25 × 15	33.7	32	21.3	18	38	38
32 × 32 × 25	42.4	38	33.7	32	48	48
32 × 32 × 20	42.4	38	26.9	25	48	48
32 × 32 × 15	42.4	38	21.3	18	48	48
40 × 40 × 32	48.3	45	42.4	38	57	57
40 × 40 × 25	48.3	45	33.7	32	57	57
40 × 40 × 20	48.3	45	26.9	25	57	57
40 × 40 × 15	48.3	45	21.3	18	57	57
50 × 50 × 40	60.3	57	48.3	45	64	60
50 × 50 × 32	60.3	57	42.4	38	64	57
50 × 50 × 25	60.3	57	33.7	32	64	51
50 × 50 × 20	60.3	57	26.9	25	64	44
65 × 65 × 50	76.1 (73)	76	60.3	57	76	70
65 × 65 × 40	76.1 (73)	76	48.3	45	76	67
65 × 65 × 32	76.1 (73)	76	42.4	38	76	64
65 × 65 × 25	76.1 (73)	76	33.7	32	76	57
80 × 80 × 65	88.9	89	76.1 (73)	76	86	83
80 × 80 × 50	88.9	89	60.3	57	86	76
80 × 80 × 40	88.9	89	48.3	45	86	73
80 × 80 × 32	88.9	89	42.4	38	86	70
90 × 90 × 80	101.6	-	88.9	-	95	92
90 × 90 × 65	101.6	-	76.1 (73)	-	95	89
90 × 90 × 50	101.6	-	60.3	-	95	83
90 × 90 × 40	101.6	-	48.3	-	95	79
100 × 100 × 90	114.3	-	101.6	-	105	102
100 × 100 × 80	114.3	108	88.9	89	105	98
100 × 100 × 65	114.3	108	76.1 (73)	76	105	95
100 × 100 × 50	114.3	108	60.3	57	105	89
100 × 100 × 40	114.3	108	48.3	45	105	86
125 × 125 × 100	139.7	133	114.3	108	124	117
125 × 125 × 90	139.7	-	101.6	-	124	114
125 × 125 × 80	139.7	133	88.9	89	124	111
125 × 125 × 65	139.7	133	76.1 (73)	76	124	108
125 × 125 × 50	139.7	133	60.3	57	124	105
150 × 150 × 125	168.3	159	139.7	133	143	137
150 × 150 × 100	168.3	159	114.3	108	143	130
150 × 150 × 90	168.3	-	101.6	-	143	127
150 × 150 × 80	168.3	159	88.9	89	143	124
150 × 150 × 65	168.3	159	76.1 (73)	76	143	121
200 × 200 × 150	219.1	219	168.3	159	178	168
200 × 200 × 125	219.1	219	139.7	133	178	162
200 × 200 × 100	219.1	219	114.3	108	178	156
200 × 200 × 90	219.1	-	101.6	-	178	152
250 × 250 × 200	273	273	219.1	219	216	203
250 × 250 × 150	273	273	168.3	159	216	194
250 × 250 × 125	273	273	139.1	133	216	191
250 × 250 × 100	273	273	114.3	108	216	184
300 × 300 × 250	323.9	325	273	273	254	241
300 × 300 × 200	323.9	325	219.1	219	254	229
300 × 300 × 150	323.9	325	168.3	159	254	219
300 × 300 × 125	323.9	325	139.7	133	254	216
350 × 350 × 300	355.6	377	323	325	279	270
350 × 350 × 250	355.6	377	273	273	279	257
350 × 350 × 200	355.6	377	219.1	219	279	248
350 × 350 × 150	255.6	377	168.3	159	279	238
400 × 400 × 350	406.4	426	355.6	377	305	305
400 × 400 × 300	406.4	426	323.9	325	305	295
400 × 400 × 250	406.4	426	273	273	305	283
400 × 400 × 200	406.4	426	219.1	219	305	273
400 × 400 × 150	406.4	426	168.3	159	305	264
450 × 450 × 400	457.2	478	406.4	426	343	330
450 × 450 × 350	457.2	478	355.6	377	343	330
450 × 450 × 300	457.2	478	323.9	325	343	321
450 × 450 × 250	457.2	478	273	273	343	308
450 × 450 × 200	457.2	478	219.1	219	343	298
500 × 500 × 450	508	529	457.2	478	381	368
500 × 500 × 400	508	529	406.4	426	381	356
500 × 500 × 350	508	529	355.6	377	381	356
500 × 500 × 300	508	529	323.9	325	381	346
500 × 500 × 250	508	529	273	273	381	333
500 × 500 × 200	508	529	219.1	219	381	324

Ukuran Pipa Norminal	Diameter Luar di Bevel				Center to End
DN	D1		D2		C	M.
DN	Seri A	Seri B	Seri A	Seri B	C	M.
350 × 350 × 300	356	377	324	325	279	270
350 × 350 × 250	356	377	273	273	279	257
350 × 350 × 200	356	377	219	219	279	248
350 × 350 × 150	356	377	168	159	279	238
400 × 400 × 350	406	426	356	377	305	305
400 × 400 × 300	406	426	324	325	305	295
400 × 400 × 250	406	426	273	273	305	283
400 × 400 × 200	406	426	219	219	305	273
400 × 400 × 150	406	426	168	159	305	264
450 × 450 × 400	457	480	406	426	343	330
450 × 450 × 350	457	480	356	377	343	330
450 × 450 × 300	457	480	324	325	343	321
450 × 450 × 250	457	480	273	273	343	308
450 × 450 × 200	457	480	219	219	343	298
500 × 500 × 450	508	530	457	480	381	368
500 × 500 × 400	508	530	406	426	381	356
500 × 500 × 350	508	530	356	377	381	356
500 × 500 × 300	508	530	324	325	381	346
500 × 500 × 250	508	530	273	273	381	333
500 × 500 × 200	508	530	219	219	381	324
550 × 550 × 500	559	-	508	-	419	406
550 × 550 × 450	559	-	457	-	419	394
550 × 550 × 400	559	-	406	-	419	394
600 × 600 × 550	610	-	559	-	432	432
600 × 600 × 500	610	630	508	530	432	432
600 × 600 × 450	610	630	457	480	432	419
650 × 650 × 600	660	-	610	-	495	483
650 × 650 × 550	660	-	559	-	495	470
650 × 650 × 500	660	-	508	-	495	457
700 × 700 × 650	711	-	660	-	521	521
700 × 700 × 600	711	720	610	630	521	521
700 × 700 × 550	711	-	559	-	521	508
750 × 750 × 700	762	-	711	-	559	546
750 × 750 × 650	762	-	660	-	559	546
750 × 750 × 600	762	-	610	-	559	533
800 × 800 × 750	813	-	762	-	597	584
800 × 800 × 700	813	820	711	720	597	572
800 × 800 × 650	813	-	660	-	597	572
850 × 850 × 800	864	-	813	-	635	622
850 × 850 × 750	864	-	762	-	635	597
850 × 850 × 700	864	-	711	-	635	597
900 × 900 × 850	914	-	864	-	673	660
900 × 900 × 800	914	920	813	820	673	648
900 × 900 × 750	914	-	762	-	673	648
950 × 950 × 900	965	-	914	-	711	711
950 × 950 × 850	965	-	864	-	711	698
950 × 950 × 800	965	-	813	-	711	686
1000 × 1000 × 950	1016	-	965	-	749	749
1000 × 1000 × 900	1016	1020	914	920	749	737
1000 × 1000 × 850	1016	-	864	-	749	724
